Wall-mounted inverter 1kW-8kW Product description for solar system
First, product characteristics
Pure sine-wave AC output
Provide high quality power output to ensure stable operation of sensitive equipment.
With automatic cutting and power charging function, to ensure the continuity of power supply.
CPU intelligent control technology ensures that the inverter can maintain efficient and stable working state under various working conditions.
High-precision SMT processing technology improves the overall performance and reliability of inverters.
Flexible working mode
Three modes are available: utility mode, ECO mode, and battery mode to meet different requirements of users.
Utility mode provides stable and continuous power output; ECO mode energy saving and efficient; Battery mode uses battery reserves to power the device.
Various charging options
Support a variety of charging types and battery types to meet the charging needs of different devices.
Lithium battery optional, lightweight and long life, suitable for long-term backup power needs.
Intelligent fan control
The fan speed is adjusted intelligently according to the working status of the inverter to ensure optimal heat dissipation.
Reduce noise and improve user experience.
Real-time display function
The LCD display displays the parameters of the device in real time, which is convenient for users to know the working status of the device at any time.
Multiple protection mechanism
Output overload protection, short circuit protection, overtemperature protection and other functions to ensure that the equipment can automatically protect in abnormal circumstances, and send alarm prompts.
Flexible system configuration
Can choose a single inverter or photovoltaic inverter control machine, to adapt to different sizes and needs of the application scenario.
Battery level protection
Second, inverter application system type
Family type household photovoltaic power generation system
Suitable for home users, electricity is generated by photovoltaic power generation system, and converted into alternating current by inverter for home use.
Renewable energy systems
Support for wind power systems, wind-solar complementary systems, and UPS power supply systems to ensure stable power in a variety of renewable energy scenarios.
Communication and transportation systems
It is used in communication base station system and highway intelligent monitoring system to ensure the stable operation of communication and traffic facilities.
Outdoor and public facilities
Suitable for outdoor billboards, government demonstration projects, landscape lighting projects, etc., to provide stable and reliable power support.
Remote areas and special environments
Island ships, remote mountains, border posts and other photovoltaic power generation systems ensure the reliability of power supply in remote or special environments.
With its superior performance, flexible configuration and wide range of application scenarios, this wall-mounted power frequency inverter is a trusted power protection solution for users.
| Rated power | 1kW-6KW |
| Battery | Rated voltage | DC 12V/24V |
| Charging voltage | 13.5V/27.5V (±2%） |
| Charging current | 20A-60A |
| Input | Voltage range | 165-260VAC |
| Frequency | 50-60Hz |
| Conreoller type | MPPT |
| Max. Solar panel charging current | 30A-60A |
| Solar panel voltage | 12V/24V(180150VDC) |
| Output | Voltage range | 220VAC ±5% （Inverter model） |
| Frequency | 50Hz/60Hz±1%(Inverter model) |
| Output wave form | Pure sine wave |
| Transfer time | <10ms (Representative load) |
| Efficiency | >85% (80% Resistive load) |
| Over load | 110-120%/30s; >160%/300ms |
| Protection | Battery over-voltage, low-voltage protection, over load, short-cut, over moistures protection, etc |
| Product dimensions (L*W*H)MM | 471*360*168 |
| Packing dimensions (L*W*H)MM | 600*440*240 |
Product Categories : Power Inverter
